RT81 4G Rugged Tablet

4G rugged tablet for store, retail, warehouse, and shipment management workflows.

10.1 inch Qualcomm Octa-core processor Data collection

Category:

Physical Parameter

Size 251*170*14.6mm
Weight <650g
Display Screen 10.1 inch IPS FHD screen (1200*1920) 400nits
Touching Screen 10 point G+G capacitive screen
Battery Capacity 3.8V/10000mAh
Interface Nano-SIM*2 TF*1(2/3) Type-C support OTG support Power Delivery 12pins Pogo Pin
Audio 2W Stereo double speakers Double MIC support noise reduction
camera Front 8 MP Rear 20 MP autofocus camera with flash
Notify motor
Key Power button SCAN button Volume button+ Volume button- Fn
Sensor gravity sensor/gyroscope sensor/ magnetic sensor

Communication Transmission

WLAN Dual-band WiFi (2.4GHz/5Ghz) Support IEEE 802.11 a/b/g/n/ac/ax ready
WWAN CN Version (China/India) 2G: GSM: GSM/GPRS/EDGE EGSM900/DCS1800 3G: WCDMA: B1/B8 4G: FDD-LTE: B1/B3/B5/B8; TDD-LTE: B34/B38/B39/B40/B41(2535-2655MHz) EAU Version (Europe/The Middle East/Africa/Korea/Thailand/Australia) 2G: GSM: GSM850/EGSM900/PCS1900/DCS1800 3G: WCDMA: B1/B2/B5/B8 4G:FDD-LTE: B1/B3/B5/B7/B8/B20/B28; TDD-LTE: B38/B40/B41(2496-2690MHz)
Bluetooth BT5.1
GNSS GPS/Glonass/Galileo

Standard function

NFC Frequency: 13.56MHz Protocol standard: ISO14443A/B,ISO15693, NFC Label standard: M1(S50 S70) CPU NFC tags Read-write distance: 2-3cm

Performance parameter

CPU QualcommSM6225 Octa-core 2.4Ghz
OS Android 13.0
RAM+ROM 4+64GB/8+128GB
Extra Memory Expansible through TF, support 256GB

Accessories

Standard Accessories Power adapter*1 USB data line*1 Battery*1 Protective film*1 Manual*1 Wrist strap*1

Optional Function

2D Scanning Engine Scanning Accuracy: ≥3mil
Independent Beidou Support independent Beidou positioning, RTK accurate positioning

Environmental Parameter

Operating Temperature -10°C-50°C
Storage Temperature -40°C-70°C
Environment Humidity 5%RH-95%RH(No condensation)
Ingress Protection IP67
Dropping Height 1.2M
