RT81 IP68 4G Rugged Tablet
IP68 rugged tablet for demanding outdoor work, data collection, and industrial mobility.
10.1 inch Qualcomm Octa-core processor Data collection
Physical Parameter
| Size | 252mm*170mm*14.6mm |
| Weight | <650g |
| Display Screen | 10.1 inch IPS FHD screen (1200*1920) 1000nits |
| Touching Screen | 10 point G+G capacitive screen |
| Battery Capacity | 3.8V/10000mAh |
| Interface | Nano-SIM*2 TF*1(2/3) Type-C support OTG support Power Delivery 12pins Pogo Pin |
| Audio | 2W Stereo double speakers Double MIC support noise reduction |
| camera | Front 8 MP Rear 16 MP, autofocus camera with flash |
| Notify | motor |
| Key | Power button SCAN button Volume button+ Volume button- Fn |
| Sensor | gravity sensor/gyroscope sensor/ magnetic sensor |
Performance parameter
| CPU | QualcommSM6225 Octa-core 2.4Ghz |
| OS | Android 13.0 |
| RAM+ROM | 4+64GB/8+128GB |
| Extra Memory | Expansible through TF, support 256GB |
Accessories
| Standard Accessories | Power adapter*1 USB data line*1 Battery*1 Protective film*1 Manual*1 Wrist strap*1 |
Communication Transmission
| WLAN | Dual-band WiFi (2.4GHz/5Ghz) Support IEEE 802.11 a/b/g/n/ac/ax ready |
| WWAN | CN Version (China/India) 2G: GSM: GSM/GPRS/EDGE EGSM900/DCS1800 3G: WCDMA: B1/B8 4G: FDD-LTE: B1/B3/B5/B8; TDD-LTE: B34/B38/B39/B40/B41(2535-2655MHz) EAU Version (Europe/The Middle East/Africa/Korea/Thailand/Australia) 2G: GSM: GSM850/EGSM900/PCS1900/DCS1800 3G: WCDMA: B1/B2/B5/B8 4G:FDD-LTE: B1/B3/B5/B7/B8/B20/B28; TDD-LTE: B38/B40/B41(2496-2690MHz) |
| Bluetooth | BT5.1 |
| GNSS | GPS/Glonass/Galileo |
Optional Function
| 2D Scanning Engine | Scanning Accuracy: ≥3mil |
| NFC | Frequency: 13.56MHz Protocol standard: ISO14443A/B,ISO15693, NFC Label standard: M1(S50 S70) CPU NFC tags Read-write distance: 2-3cm |
| Independent Beidou | Support independent Beidou positioning, RTK accurate positioning |
Environmental Parameter/h3>
| Operating Temperature | -10°C-50°C |
| Storage Temperature | -40°C-70°C |
| Environment Humidity | 5%RH-95%RH(No condensation) |
| Ingress Protection | IP68 |
| Dropping Height | 1.2M |
