Physical Parameter
| Size | 251*170*14.6mm |
| Weight | <650g |
| Display Screen | 10.1 inch IPS FHD screen (1200*1920) 400nits |
| Touching Screen | 10 point G+G capacitive screen |
| Battery Capacity | 3.8V/10000mAh |
| Interface | Nano-SIM*2 TF*1(2/3) Type-C support OTG support Power Delivery 12pins Pogo Pin |
| Audio | 2W Stereo double speakers Double MIC support noise reduction |
| Camera | Front 8.0MP Rear 48.0MP autofocus camera with LED flash Rear Macro sub camera 8.0MP (optional) |
| Notify | motor |
| Key | Power button SCAN button Volume button+ Volume button- Fn |
| Sensor | Gravity sensor/Gyroscope sensor/ Magnetic sensor |
Communication Transmission
| WLAN | Dual-band WIFI (2.4GHz/5Ghz)Support IEEE 802.11 a/b/g/n/ac |
| WWAN | 3G WCDMA: B1/B5/B84G LTE MINO: B1/B3/B414G LTE: B1/B3/B5/B8/B34/B38/B39/B40/B415G MIMO: N1/N41/N78/N795G SA/NSA: N1/N3/N5/N8/N28/N41/N78/N79 |
| Bluetooth | BT 5.0 |
| GNSS | GPS/Glonass/Galileo |
Optional Function
| 2D Scanning Engine | Scanning Accuracy: ≥3mil |
| NFC | Frequency: 13.56MHz Protocol standard: ISO14443A/B,ISO15693, NFC Label standard: M1(S50 S70) CPU NFC tags Read-write distance: 2-3cm |
| Independent Beidou | Support independent Beidou positioning, RTK accurate positioning |
| Fingerprint | Support fingerprint unlocking |
Performance parameter
| CPU | Unisoc UIS7885 Octa-core 2.7Ghz 8T NPU |
| OS | Android 13.0/Harmony OS |
| RAM+ROM | 6+128GB |
| Extra Memory | Expansible through TF, support 512GB |
Environmental Parameter
Accessories
Technical Specification
| Operating Temperature | -10°C-50°C |
| Storage Temperature | -40°C-70°C |
| Environment Humidity | 5%RH-95%RH(No condensation) |
| Ingress Protection | IP67 |
Standard Accessories
Power adapter*1 USB data line*1 Battery*1 Protective film*1 Manual*1 Wrist strap*1
